Ethernet Industrial 4.0 EIP-C5
Ethernet Industrial 4.0 EIP-C5 cables are engineered for high-performance industrial Ethernet applications, providing robust and reliable data transmission in demanding environments. These cables are ideal for use in industrial automation systems, ensuring seamless communication between devices and systems.
APPLICATION :
Ethernet Industrial Cable, Cat.5e, extra flexible, for use in cable chains with movement speed of up to 180m/min. Halogen free and flame retardant cable.
| Conductor | Fine threads of copper (AWG26/19) |
|---|---|
| Insulation | Thermoplastic polymer |
| Identification | white/blue-blue, white/orange-orange, white/green-green, white/brown-brown |
| Cabling | 4 pairs in the set with fillings |
| Shielding | Shielding of tinned copper braid, coverage of 90% |
| Exterior sheath | Polyurethane, green colour |
| IEC 60332-1-2 | Flame retardant |
|---|---|
| IEC 60811-2-1 | Resistance to oils and industrial greases |
| IEC 60754-1 | Halogen free |
| Impedance (f=100MHz) | 100 Ohm +/-5 Ohm |
|---|---|
| Bandwidth | 1-100 MHz |
| Minimum bend radius | 8 x diámetro exterior |
| Service temperature | -20ºC to +80ºC |
| Max. movement speed | 180m/min. |
| Max. acceleration/deceleration | 5 m/s² |
| Max. horizontal movement | distance 25 m |
| Number of cycles | Min. 1 mio. / Max. 10 mio. Depending on the exact application. For more information, contact your technical sales manager. |
- Tool Machine
- Automation
- Packaging
- Food & Beverage
- Chemical Industry
- Pharmaceutical Industry
- Glass and Ceramics Industry
- Aeronautical Industry
- Transport & Logistics
